PK 880 TEC

• More intelligent operation with PALTRONIC 180 control electronics
• Extra smooth control thanks to LX-6 control valve
• Very stiff and light boom system thanks to P-Profile
• More efficient and faster due to continuous slewing system
• More efficiency with fly jib due to DPS-C
• Maximum utilisation of the working range thanks to extended HPSC
• More lifting power due to S-HPLS
• Practical and attractive due to Functional Design

Technical data

Max. lifting moment	82,8 mt
Max. lifting capacity	25000 kg
Max. hydraulic outreach	21,7 m
Slewing angle	∞
Stabiliser spread (std)	8.6 m
Fitting space required (std)	1,64 m
Width folded	2,55 m
Max. operating pressure	385 bar
Pump capacity	2 x 100 - 130 l/m
Weight	7160 t
Slewing torque with 2 gears	8,4 mt

Technical data

	Lifting moment	Outreach	Slewing angle	Slewing torque	Pressure	Pump capacity	Crane weight	Crane height	Crane width	Installation width	Max stroke length	Max. lifting capacity	Load vertical
C	82.8 mt	10.9 m	∞ °	8.4 mt mt	38.5 Mpa	2 x 100 - 130 l/min l/min	7160 kg	2505 m	2550 m	1640 mm	10.7 m	-
D	82.8 mt	12.9 m	∞ °	8.4 mt mt	38.5 Mpa	2 x 100 - 130 l/min l/min	7450 kg	2505 mm	2550 mm	1640 mm	12.8 m	-	-
E	82.8 mt	15.0 m	∞ °	8.4 mt mt	38.5 Mpa	2 x 100 - 130 l/min l/min	7740 kg	2505 mm	2550 mm	1720 mm	14.8 m	-	-
F	82.8 mt	17.2 m	∞ °	8.4 mt mt	38.5 Mpa	2 x 100 - 130 l/min l/min	8010 kg	2505 mm	2550 mm	1720 mm	17 m	-	-
G	82.8 mt	19.5 m	∞ °	8.4 mt mt	38.5 Mpa	2 x 100 - 130 l/min l/min	8250 kg	2505 mm	2550 mm	1820 mm	19.4 m	-	-
H	82.8 mt	21.7 m	∞ °	8.4 mt mt	38.5 Mpa	2 x 100 - 130 l/min l/min	8450 kg	2505 mm	2550 mm	1820 mm	21.5 m	-	-
