PK 580 TEC
  • More intelligent operation with PALTRONIC 180 control electronics
  • Extra smooth control thanks to LX-6 control valve
  • Very stiff and light boom system thanks to P-Profile
  • More efficient and faster due to continuous slewing system
  • High user friendliness due to in-house developed radio remote control PALcom P7
  • More efficiency with fly jib due to DPS-C
  • Maximum utilisation of the working range thanks to extended HPSC
  • More lifting power due to S-HPLS
  • Practical and attractive due to Functional Design

Technical data

Max. lifting moment 55,5 mt
Max. lifting capacity 20000 kg
Max. hydraulic outreach 21,2 m
Slewing angle
Stabiliser spread (std) 7.8m m
Fitting space required (std) 1,43 m
Width folded 2,55 m
Max. operating pressure 385 bar
Pump capacity 90 - 120 l/m
Weight 4670 t
Slewing torque with 2 gears 5,9 mt

Technical data

Lifting moment Outreach Slewing angle Slewing torque Pressure Pump capacity Crane weight Crane height Crane width Installation width Max stroke length Max. lifting capacity Load vertical
A 54.7 mt 7.9 m ∞ ° 5.9 mt 38.5 Mpa 90-120 l/min 4670 kg 2460 mm 2550 mm 1440 mm 7700 mm - 7100 kg
B 53.1 mt 9.9 m ∞ ° 5.9 mt 38.5 Mpa 90-120 l/min 4950 kg 2460 mm 2550 mm 1440 mm 9800 mm - 5500 kg
C 52.3 mt 12.0 m ∞ ° 5.9 mt 38.5 Mpa 90-120 l/min 5200 kg 2460 mm 2550 mm 1440 mm 11900 mm - 4300 kg
D 51.5 mt 14.3 m ∞ ° 5.9 mt 38.5 Mpa 90-120 l/min 5470 kg 2460 mm 2550 mm 1440 mm 14100 mm - 3350 kg
E 50.7 mt 16.6 m ∞ ° 5.9 mt 38.5 Mpa 90-120 l/min 5720 kg 2460 mm 2550 mm 1525 mm 16500 mm - 2700 kg
F 50.1 mt 18.9 m ∞ ° 5.9 mt 38.5 Mpa 90-120 l/min 5950 kg 2460 mm 2550 mm 1525 mm 18800 mm - 2150 kg
G 49.6 mt 21.2 m ∞ ° 5.9 mt 38.5 Mpa 90-120 l/min 6100 kg 2460 mm 2550 mm 1525 mm 21100 mm - 1780 kg
